All Flash Arrays: SSD-based versus Ground-Up Design


In recent articles in this series I’ve been looking at the architectural choices for building All Flash Arrays (AFAs). I surmised that there are three main approaches:

  • Hybrid Flash Arrays
  • SSD-based All Flash Arrays
  • Ground-Up All Flash Arrays (which from here on I’ll refer to as Custom Flash Module arrays or CFM arrays)

I’ve already blown metaphorical raspberries at the hybrid approach, so now it’s time to cover the other two.

SSD or CFM: The Big Question

I think the most interesting question in the AFA industry right now is the one of whether the SSD or CFM design will win. Of course, it’s easy to say “win” like that as if it’s a simple race, but this is I.T. – there’s never a simple answer. However, the reality is that each method offers benefits and drawbacks, so I’m going to use this blog post to simply describe them as I see them.

Before I do that, let me just remind you of what the vendor landscape looks like at this time:

SSD-based architecture: Right now you can buy SSD-based arrays from EMC (XtremIO), Pure Storage, Kaminario, Solidfire, HP 3PAR and Huawei to name a few. It’s fair to say that the SSD-based design has been the most common in the AFA space so far.

CFM-based architecture: On the other hand, you can now buy ground-up CFM-based arrays from Violin Memory, IBM (FlashSystem), HDS (VSP), Pure Storage (FlashArray//m) and EMC (DSSD). The latter has caused some excitement because of DSSD’s current air of mystery in the marketplace – in other words, the product isn’t yet generally available.

So which approach is “the best”?

The SSD-based Approach

If you were going to start an All Flash Array company and needed to bring a product to market as soon as possible, it’s quite likely you would go down the SSD route. Apart from anything else, flash management is hard work – and needs constant attention as new types of flash come to market. A flash hardware engineer friend of mine used to say that each new flash chip is like a snowflake – they all behave slightly differently. So by buying flash in the ready-made form of an SSD you bypass the requirement to put in all this work. The flash controller from the SSD vendor does it for you, leaving you to concentrate on the other stuff that’s needed in enterprise storage: resilience, availability, data services, etc.Samsung_840_EVO_SSD

On the other hand, it seems clear that an SSD is a package of flash pretending to behave like a disk. That often means I/Os are taking place via protocols that were designed for disk, such as Serial Attached SCSI. Also, in a unit the size of an all flash array there are likely to be many SSDs… but because each one is an isolated package of flash, they cannot work together and manage the flash holistically. In other words, if one SSD is experiencing issues due to garbage collection (for example), the others cannot take the strain.

The Ground-Up Approach

For a number of years I worked for Violin Memory, which adopts the ground-up approach at its very core. Violin’s position is that only the CFM approach can unlock the full potential benefits from NAND flash. By tightly integrating the NAND flash into its array – and by using its own controllers to manage that flash – Violin believes it has been able to deliver the best performance in the AFA market. On the other hand, many SSD vendors build products for the consumer market where the highest levels of performance simply aren’t necessary. All that’s required is something faster than disk – it doesn’t always have to be the fastest possible solution.electronics

It could also be argued that any CFM vendor who has a good relationship with a flash fabricator (for example, Violin is partly-owned by Toshiba) could gain a competitive advantage by working on the very latest NAND flash technologies before they are available in SSD form. What’s more, SSDs represent an additional step in the process of taking NAND flash from chip to All Flash Array, which potentially means there’s an extra party needing to make their margin. Could it be that the CFM approach is more cost effective?

SSD Economics

The argument about economics is an interesting one. Many technical people have a tendency to focus on what they know and love: technology. I’m as guilty of this as anyone – given two solutions to a problem I tend to gravitate toward the one that has the most elegant technical design, even if it isn’t necessarily the most commercially-favourable. Taking raw flash and integrating it into a custom flash module sounds great, but what is the cost of manufacturing those CFMs?

moneyManufacturing is all about economies of scale. If you design something and then build thousands of them, it will obviously cost you more per unit than if you build millions of them. How many ground-up all flash vendors are building their custom flash modules by the millions? In May 2015, IBM issued this press release in which they claimed that they were the “number one all-flash storage array vendor in 2014“. How many units did they ship? 2,100.

In just the second quarter of 2015, almost 24 million SSDs were shipped to customers, with Samsung responsible for 43.8% of that total (according to US analyst firm Trendfocus, Inc). Who do you think was able to achieve the best economy of scale?

Design Agility

The other important question is the one about New Stuff ™. We are always being told about fantastic new storage technologies that are going to change our lives, so who is best placed to adopt them first?

Again there’s an argument to be made on both sides. If the CFM flash vendor is working hand-in-glove with a fabricator, they may have access to the latest technology coming down the line. That means they can be prepared ahead of the pack – a clear competitive advantage, right?

But how agile is the CFM design? Changing the NVM media requires designing an entirely-new flash module, with all the associated hardware engineering costs such as prototyping, testing, QA and limited initial manufacturing runs.

For an SSD all flash array vendor, however, that work is performed by the SSD vendor… again somebody like Samsung, Intel or Micron who have vast infrastructures in place to perform that sort of work all the time. After all, a finished SSD must behave exactly like a disk, regardless of what NVM technology it uses under the covers.


There are obviously two sides to this argument. The SSD was designed to replace a fundamental bottleneck in storage systems: the hard disk drive. Ironically, it may be the fate of the SSD to become exactly what it replaced. For flash to become mainstream it was necessary to create a “flash-behaving-as-disk” package, but the flip side of this is the way that SSDs stifle the true potential of the underlying flash. (Although perhaps NVMe technologies will offer us some salvation…)question-mark-dice

However, unless you are a company the size of Samsung, Intel or Micron it seems unlikely that you would be able to retain the manufacturing agility and economies of scale required to produce custom flash modules at the price point of SSDs. Nor would you be likely to have the agility to adopt new NVM technologies at the moment that they become economically preferable to whatever medium you were using previously.

Whatever happens, you can be sure that each side will claim victory. With the entire primary data market to play for, this is a high stakes game. Every vendor has to invest a large amount of money to enter the field, so nobody wants to end up being consigned to the history books as the Betamax of flash…

For younger readers, Betamax was the loser in a battle with VHS over who would dominate the video tape market. You can read about it here. What do you mean, “What is a video tape?” Those things your parents used to watch movies on before the days of DVDs. What do you mean, “What is a DVD?” Jeez, I feel old.

All Flash Arrays: Where’s My Capacity? Effective, Usable and Raw Explained


What’s the most important attribute to consider when you want to buy a new storage system? More critical than performance, more interesting than power and cooling requirements, maybe even more important than price? Whether it’s an enterprise-class All Flash Array, a new drive for your laptop or just a USB flash key, the first question on anybody’s mind is usually: how big is it?

Yet surprisingly, at least when it comes to All Flash Arrays, it is becoming increasingly difficult to get an accurate answer to this question. So let’s try and bring some clarity to that in this post.

Before we start, let’s quickly address the issue of binary versus decimal capacity measurements. For many years the computer industry has lived with two different definitions for capacity: memory is typically measured in binary values (powers of two) e.g. one kibibyte = 2 ^ 10 bytes = 1024 bytes. On the other hand, hard disk drive manufacturers have always used decimal values (powers of ten) e.g. one kilobyte = 10 ^ 3 bytes = 1000 bytes. Since flash memory is commonly used for the same purpose as disk drives, it is usually sold with capacities measured in decimal values – so make sure you factor this in when sizing your environments.


Now that’s covered, let’s look at the three ways in which capacity is most commonly described: raw capacity, usable capacity and effective capacity. To ensure we don’t stray from the truth, I’m going to use definitions from SNIA, the Storage Networking Industry Association.

Raw Capacity: The sum total amount of addressable capacity of the storage devices in a storage system.

rawThe raw capacity of a flash storage product is the sum of the available capacity of each and every flash chip on which data can be stored. Imagine an SSD containing 18 Intel MLC NAND die packages, each of which has 32GB of addressable flash. This therefore contains 576GB of raw capacity. The word addressable is important because the packages actually contain additional unaddressable flash which is used for purposes such as error correction – but since this cannot be addressed by either you or the firmware of the SSD, it doesn’t count towards the raw value.

Usable Capacity: (synonymous with Formatted Capacity in SNIA terminology) The total amount of bytes available to be written after a system or device has been formatted for use… [it] is less than or equal to raw capacity.

usablePossibly one of the most abused terms in storage, usable capacity is what you have left after taking raw capacity and removing the space set aside for system use, RAID parity, over-provisioning (i.e. headroom for garbage collection) and so on. It is guaranteed capacity, meaning you can be certain that you can store this amount of data regardless of what the data looks like.

That last statement is important once data reduction technologies come into play, i.e. compression, deduplication and thin provisioning. Take 10TB of usable space and write 5TB of data into it – you now have 5TB of usable capacity remaining. Sounds simple? But take 10TB of usable space and write 5TB of data which dedupes and compresses at a 5:1 ratio – now you only need 1TB of usable space to store it, meaning you have 9TB of usable capacity left available.

Effective Capacity: The amount of data stored on a storage system … There is no way to precisely predict the effective capacity of an unloaded system. This measure is normally used on systems employing space optimization technologies.

effectiveThe effective capacity of a storage system is the amount of data you could theoretically store on it in certain conditions. These conditions are assumptions, such as “my data will reduce by a factor of x:1”. There is much danger here. The assumptions are almost always related to the ability of a dataset to reduce in some way (i.e. compress, dedupe etc) – and that cannot be known until the data is actually loaded. What’s more, data changes… as does its ability to reduce.

For this reason, effective capacity is a terrible measurement on which to make any firm plans unless you have some sort of guarantee from the vendor. This takes the form of something like, “We guarantee you a minimum of 3:1 data reduction – and if you fail to realise this we will provide you with additional storage free of charge“.

The most commonly used assumptions in the storage industry are that databases reduce by around 2:1 to 4:1, VSI systems around 5:1 to 6:1 and VDI systems anything from 8:1 right up to 18:1 or even further. This means an average data reduction of around 6:1, which is the typical ratio you will see on most vendor’s data sheets. If you take 10TB of usable capacity and assume an average of 6:1 data reduction, you therefore end up with an effective capacity of 60TB. Some vendors use a lower ratio, such as 3:1 – and this is good for you the customer, because it gives you more protection from the risk of your data not reducing.

But it’s all meaningless in the real world. You simply cannot know what the effective capacity of a storage system is until you put your data on it. And you cannot guarantee that it will remain that way if your data is going to change. Never, ever buy a storage system based purely on the effective capacity offered by the vendor unless it comes with a guarantee – and always consider whether the assumed data reduction ratio is relevant to you.

Use and Abuse of Capacities

Three different ways to measure capacity? Sounds complicated. And in complexity comes opportunities for certain flash array vendors to use smoke and mirrors in order to make their products seem more appealing. I’m going to highlight what I think are the two most common tactics here.

1. Confusing Usable Capacity with Effective Capacity

Many flash array vendors have Always-On data reduction services. This is often claimed to be for the customer’s benefit but is often more about reducing the amount of writes taking place to the flash media (to alleviate performance and endurance issues). For some vendors, not having the ability to disable data reduction can be spun around to their advantage: they simply make out that the terms usable and effective are synonymous, or splice them together into the unforgivable phrase effective usable capacity to make their products look larger. How convenient.

Let me tell you this now: every flash array has a usable capacity… it is the maximum amount of unique, incompressible data that can be stored, i.e. the effective capacity if the data reduction ratio were 1:1. I would argue that this is a much more important figure to know when you buy a flash system, because if you buy on effective capacity you are just buying into dreams. Make your vendor tell you the usable capacity at 1:1 data reduction and then calculate the price per GB based on that value.

2. My Data Reduction Is Better Than Yours

Every flash vendor thinks their data reduction technologies are the best. At Violin I saw evidence to suggest that’s their data reduction was superior to two well-known alternative brands of AFA. But talk to each vendor in turn and they’ll tell you the same. Sometimes they’ll make claims so utterly ridiculous that you’ll think it’s actually a joke. I guess we all believe what we want to hear. And from there on it’s only a small step to try and convince you that they can deliver a better data reduction ratio – so their effective capacity must be higher, right? Beware.

Here’s the truth. Compression and deduplication are mature technologies – they have been around for decades. Nobody in the world of flash storage is going to suddenly invent something that is remarkably better than the competition. Sometimes one vendor’s tech might deliver better results than another, but on other days (and, crucially, with other datasets) that will reverse. For this reason, as well as for your own sanity, you should assume they will all be roughly the same… at least until you can test them with your data. When you evaluate competitive flash products, pick a data reduction ratio that suits you and then use it for all vendors.


Don’t let your vendors set the agenda when it comes to sizing. If you are planning on buying a certain capacity of flash, make sure you know the raw and usable capacities, plus the effective capacity and the assumed data reduction ratio used to calculate it. Remember that usable should be lower than raw, while effective (which is only relevant when data reduction technologies are present) will commonly be higher.

Keep in mind that Effective Capacity = Usable Capacity X Data Reduction Factor.

Be aware that when a product with an “Always-On” data reduction architecture tells you how much capacity you have left, it’s basically a guess. In reality, it’s entirely dependent on the data you intend to write. I’ve always thought that “Always-On” was another bit of marketing spin; you could easily rename it as an “Unavoidable” or “No Choice” architecture.

In my opinion, the best data reduction technology will be selectable and granular. That means you can choose, at a LUN level, whether you want to take advantage of compression and deduplication or not – you aren’t tied in by the architecture. Like with all features, the architecture should allow you to have a choice rather then enforce a compromise.

So there we have it: clarity and choice. Because in my opinion – and no matter which way you measure it – one size simply doesn’t fit all.

All Flash Arrays: Can’t I Just Stick Some SSDs In My Disk Array?


In the previous post of this series I outlined three basic categories of All Flash Array (AFA): the hybrid AFA, the SSD-based AFA and the ground-up AFA. This post addresses the first one and is therefore aimed at answering one of the questions I hear most often: why can’t I just stick a bunch of SSDs in my existing disk array?

Data Centre Dinosaurs

Disk arrays – and in this case we are mainly talking about storage area networks – have been around for a long time. Every large company has a number of monolithic, multi-controller cache-based disk arrays in their data centre. They are the workhorses of storage: ever reliable, able to host multiple, mixed workloads and deliver predictable performance. Predictably slow performance, of course – but you mustn’t underestimate just how safe these things feel to the people who are paid to ensure the safety of their data. Add to this the full suite of data services that come with them (replication, mirroring, snapshots etc) and you have all that you could ask for.



Except of course that they are horribly expensive, terribly slow and use up vast amounts of power, cooling and floor space. They are also a dying breed, memorably described by Chris Mellor of The Register as like outdated battleships in an era of modern warfare.

The SSD Power-Up

Every large vendor has a top-end product: EMC’s VMAX, IBM’s DS8000, HDS’s VSP… and pretty much every product has the ability to use SSDs in place of disk drives. So why not fill one of these monsters with flash drives and then call it an “All Flash Array”? Just like in those computer games where your spacecraft hits a power-up and suddenly it’s bigger and faster with better weapons… surely a bunch of SSDs would convert your ageing battleship into a modern cruiser with new-found agility and seaworthiness. Ahoy! [Ok, I’ll stop with the naval analogies now]

Well, no. And to understand why, let’s look at how most disk arrays are architected.

The Classic Disk Array Architecture

Let’s consider what it takes to build a typical SAN disk array. We’ll start with the most obvious component, which is the hard disk drive itself. These things have been around for decades so we are fairly familiar with them. They offer pretty reasonable capacity of up to 4TB (in fact there are even a few 6TB models out now) but they have a limitation with regard to performance: you are unlikely to be able to drive much more than 200 transactions per second.

At this point, stop and think about the performance characteristics of a hard disk drive. Disks don’t really care if you are doing read or write I/Os – the performance is fairly symmetrical. However, there is a drastic difference in the performance of random versus sequential I/Os: each I/O operation incurs the penalty of latency. A single, large I/O is therefore much more efficient than many, small I/Os.

This is the architectural constraint of every hard disk drive and therefore the design challenge around which we much architect our disk array.

In the next section we’re going to build a disk array from scratch, considering all the possibilities that need to be accounted for. If it looks like it will take too long to read, you can skip down to the conclusion section at the end.

Building A Disk Array

We’re now going to build a disk array, so the first ingredient is clearly going to be hard drives. So let’s start by taking a bunch of disks and putting them into a shelf, or some other form of enclosure:


At this point the density is limited by the number of disks we can fit into the enclosure, which might typically be 25 if they are of the smaller form factor or up to around 14 if they are the larger 3.5 inch variety.

Next we’re going to need a controller – and in that controller we’re going to want a large chunk of DRAM to act as a cache in order to try and minimise the number of I/Os hitting the disk enclosure. We’ll allocate some of that DRAM to work as a read cache, in the hope that many of the reads will be hitting a small subset of the data stored, i.e. the “hot” blocks. If this gamble is successful we will have taken some load off of the disks – and that is a Good Thing:


The rest of the DRAM will be allocated to a write cache, because clearly we don’t want to have to incur the penalty of rotational latency every time a write I/O is performed. By writing the data to the DRAM buffer and then issuing the acknowledgement back to the client, we can take our time over writing the data to the persistent storage in the disk enclosure.

Now, this is an enterprise-class product we are trying to build, so that means there are requirements for resiliency, redundancy, online maintenance etc. It therefore seems pretty obvious that having only one controller is a single point of failure, so let’s add another one:


This brings up a new challenge concerning that write cache we just discussed. Since we are acknowledging writes when they hit DRAM it could be possible for controller to crash before changed blocks are persisted to disk – resulting in data loss. Also, an old copy of a block could be in the cache of one controller while a newly-changed version exists in the other one. These possibilities cannot be allowed, so we will need to mirror our write cache between the controllers. In this setup we won’t acknowledge the write until it’s been written to both write caches.

Of course, this introduces a further delay, so we’ll need to add some sort of high speed interconnect into the design to make the process of mirroring as fast as possible:


This mirroring may protect us from losing data in the event of a single controller failure, but what about if power to the entire system was lost? Changed blocks in the mirrored write cache would still be lost, resulting in lost data… so now we need to add some batteries to each controller in order to provide sufficient power that cached writes can be flushed to persistent media in the event of any systemic power issue:


That’s everything we need from the controllers – so now we need to connect them together with the disks. Traditionally, disk arrays have tended to use serial architectures to attach disks onto a back end network which essentially acts as a loop. This has some limitations in terms of performance but when your fundamental building blocks are each limited to 200 IOPS it’s hardly the end of the world:


So there we have it. We’ve built a disk array complete with redundant controllers and battery-backed DRAM cache. Put a respectable logo on the front and you will find this basic design used in data centres around the world.

But does it still make sense if you switch to flash?


Let’s take our finished disk array design and replace the disks with SSDs:


And now let’s take a moment to consider the performance characteristics of flash: the latency is much lower than disk, meaning the penalty for performing random I/Os instead of sequential I/Os is negligible. However, the performance of read versus write I/Os is asymmetrical: writes take substantially longer than reads – especially sustained writes. What does that do to all of the design principles in our previous architecture?

  • With so many more transactions per second available from the SSDs, it no longer makes sense to use a serial / loop based back end network. Some sort of switched infrastructure is probably more suitable.
  • Because the flash media is so much faster than disk (i.e. has a significantly lower latency), we can do away with the read cache. Depending on our architecture, we may also be able to avoid using a write cache too – resulting in complete removal of the DRAM in those controllers (although this would not be the case if deduplication were to be included in the design – more on that another time).
  • If we no longer have data in DRAM, we no longer need the batteries and may also be able to remove or at least downsize the high speed network connecting the controllers.

All we are left with now is the enclosure full of SSDs – and there is an argument to be made for whether that is the most efficient method of packaging NAND flash. It’s certainly not the most dense method, which is why Violin Memory and IBM’s FlashSystem both use their own custom flash modules to package their flash.


Did you notice how pretty much every design decision that we made building the disk array architecture turned out to be the wrong one for a flash-based solution? This shouldn’t really be a surprise, since flash is fundamentally different to disk in its behaviour and performance.

Battleship Down!

Battleship Down!

Architecture matters. Filling a legacy disk array with SSDs simply isn’t playing to the strengths of flash. Perhaps if it were a low cost option it would be a sensible stop-gap solution, but typically the SSD options for these legacy arrays are astonishingly expensive.

So next time you look at a hybrid disk array product that’s being marketed as “all flash”, do yourself a favour. Think about the architecture. If it was designed for disk, the chances are it’ll perform like it was designed for disk. And you don’t want to end up with that sinking feeling…

Thanks to my friend and former colleague Steve “yeah” Willson for the concepts behind this blog post. Steve, I dedicate the picture of a velociraptor at the top of this page to you. You have earned it.

Understanding Flash: Summary – NAND Flash Is A Royal Pain In The …


So this is it – the last article in my mini-series on understanding flash. This is the bit where I draw it all together in a neat conclusion that makes you think, “Yes! That was worth reading”. No pressure eh?

So let me start with the conclusion first: as a storage medium, NAND flash is a royal pain in the ass.


Why? Well, let’s look back at what we’ve learned in the previous 9 articles:

In short, NAND flash is a tricky medium to use for enterprise storage. A whole lot of work is required to make a collection of flash chips appear to be a unified, resilient block of storage with fast, predictable performance.

And I haven’t even told you everything. Consider, for example, the phenomenon of read disturb. When you read a page within a NAND flash chip, you cause a very minor electronic field in the locality of the cells it contains. That field will cause a small disturbance to any neighbouring cells – usually not enough to cause concern, but significant nevertheless. So what happens when you repeatedly read that page? Eventually, after X number of reads, the data stored within the nearby cells becomes questionable.

NAND-flashThe solution, therefore, is to keep track of the number of times each page is disturbed in this manner and then set a threshold (let’s say 50 disturbances) beyond which you will copy the data out to a clean page and then mark the old page as stale. Easy.

But just think about what that means for a moment. Remember when I said that write amplification was mainly impacted by write workloads? This new piece of information means that even on a 100% read workload there will be additional back-end writes taking place on the array. Just another example of why flash is a tricky medium to manage.


Of course, it would be remiss of me not to mention that NAND flash brings a tremendous set of benefits along with these problems. You could say they come as a package (oh come on, that was one of my better puns).

Let’s go back to basics for a moment: if you want to take a defined quantity of work and do it in a shorter amount of time, what are your choices? Put simply, there are two options: do the same work faster, or do more of it in parallel (and of course both options can be used together for extra gain).

The basic building block of a disk array is, obviously, the hard disk drive. I’ve already explained at tedious length about the performance gap between disk and flash, so we know that we can access data faster using flash. Technologies like RAID allow multiple disks to be used in parallel to achieve performance (and resilience) gains, but given a limited amount of physical space (such as a data centre rack), how many hard drives can you actually squeeze into one system?

Now compare this to the number of NAND flash packages you could fit into the same space, all of which you could potentially utilise in parallel and at a lower latency. Doing the same work faster – and doing more of it in parallel.

Image courtesy of Google Inc.

Image courtesy of Google Inc.

And there’s more. Those clunky great big cabinets of disk use up horrendous amounts of power just to spin those little rotating platters – with much of the energy converted to heat and noise: waste. The heat results in a requirement for additional cooling, which uses even more power: more waste. And it all takes up so much physical space that data centres become overrun with storage.

In contrast, all flash arrays (AFAs) require less power, less cooling and take up less physical space: it’s not uncommon for customers to pay for the move to flash simply by avoiding the need to build a new data centre or extend an existing one. In summary, the net cost of using flash is now less than that of using disk.

When I first started writing this blog back in 2012 there was still a debate over whether flash would replace disk for enterprise storage. That debate was over some time ago: flash has already won.

Architecture Matters

So this post marks the end of my journey into explaining and understanding NAND flash. Yet there is a whole new area which needs exploring: the architecture of all flash arrays.

Enterprise storage needs be safe, reliable, predictable and fast. Yet at a package level, NAND flash is a tricky little beast that has to be constantly watched to make sure it behaves itself. There’s a dichotomy here: how do we use the latter to deliver the former? How do we take a component designed for consumer electronics and use it to build an enterprise-class AFA? In short, how we derive order from chaos?

architectureThe answer is in the architecture. At the time of writing this blog there are a number of AFA vendors on the market, each with a different approach to taming the beast. Apart from my own employer, Violin Memory, there is EMC, IBM, HDS, Pure Storage, SolidFire, Kaminario and a whole load more.

And that’s why this industry is so interesting to me. Everybody is trying to do this differently, although you can broadly categorise the solutions into three distinct ranges: hybrid arrays, SSD-based arrays and ground-up arrays. Everybody thinks their way is right – and nobody can afford to be wrong. The market for flash-based primary storage is huge and growing all the time: the winners get unparalleled success, while the losers … are simply left in disarray*

*I won’t lie – I’m so proud of that pun I’m going to award myself a couple of weeks off.

The Great Hypervisor Bake-off: VMware ESX vs Oracle VM


This is a very simple post to show the results of some recent testing that Tom and I ran using Oracle SLOB on Violin to determine the impact of using virtualization. But before we get to that, I am duty bound to write a paragraph of text featuring lots of long sentences peppered with industry buzz words. Forgive me, it’s just the way I’m wired.

It is increasingly common these days to find database environments running in virtual machines – even large, business critical ones. The driver is the trend to commoditize I.T. services and build consolidated, private-cloud style solutions in order to control operational expense and increase agility (not to mention reduce exposure to Oracle licenses). But, as I’ve said in previous posts, the catalyst has been the unblocking of I/O as legacy disk systems are replaced by flash memory. In the past, virtual environments caused a kind of I/O blender effect whereby I/O calls become increasingly randomized – and this sucked for the performance of disk drives. Flash memory arrays on the other hand can deliver random I/O all day long because… well, if you don’t know the reasons by now can I just recommend starting at the beginning. The outcome is that many large and medium-sized organisations are now building database-as-a-service platforms with Oracle databases (other database products are available) running in virtual machines. It’s happening right now.

Phew. Anyway, that last paragraph was just a wordy way of telling you that I’m often seeing Oracle running in virtual machines on top of hypervisors. But how much of a performance impact do those hypervisors have? Step this way to find out.

The Contenders

boxersWhen it comes to running Oracle on a hypervisor using Intel x86 hardware (for that is what I have available), I only know of three real contenders:

Hyper-V has been an option for a couple of years now, but I’ll be honest – I have neither the time nor the inclination to test it today. It’s not that I don’t rate it as a product, it’s just that I’ve never used it before and don’t have enough time to learn something new right now. Maybe someday I’ll come back and add it to the mix.

In the meantime, it’s the big showdown: VMware versus Oracle VM. Not that Oracle VM is really in the same league as VMware in terms of market share… but you know, I’m trying to make this sound exciting.

The Test

This is going to be an Oracle SLOB sustained throughput test. In other words, I’m going to build an Oracle database and then shovel a massive amount of I/O through it (you can read all about SLOB here and here). SLOB will be configured to run with 25% of statements being UPDATEs (the remainder are SELECTs) and will run for 8 hours straight. What we want to see is a) which hypervisor configuration allows the greatest I/O bandwidth, and b) which hypervisor configuration exhibits the most predictable performance.

This is the configuration. First the hardware:

Violin Memory 6616 flash Memory Array

Violin Memory 6616 flash Memory Array

  • 1x Dell PowerEdge R720 server
  • 2x Intel Xeon CPU E5-2690 v2 10-core @ 3.00GHz [so that’s 2 sockets, 20 cores, 40 threads for this server]
  • 128GB DRAM
  • 1x Violin Memory 6616 (SLC) flash memory array [the one that did this]
  • 8GB fibre-channel

And the software:

  • Hypervisor: VMware ESXi 5.5.1
  • Hypervisor: Oracle VM for x86 3.3.1
  • VM: Oracle Linux 6 Update 5 (with the Unbreakable Enterprise v3 Kernel 3.6.18)
  • Oracle Grid Infrastructure (for Automatic Storage Management)
  • Oracle Database Enterprise Edition

Each VM is configured with 20 vCPUs and is using Linux Device Mapper Multipath and Oracle ASMLib. ASM is configured to use one single +DATA disgroup comprising 8 ASM disks (LUNs from Violin) with external redundancy. The database parameters and SLOB settings are all listed on the SLOB sustained throughput test page.

Results: Bare Metal (Baseline)

First let’s see what happens when we don’t use a hypervisor at all and just run OL6.5 on bare metal:

Oracle SLOB- 8 Hour Sustained Throughput Test with no hypervisor (SLC)

IO Profile                  Read+Write/Second     Read/Second    Write/Second
~~~~~~~~~~                  ----------------- --------------- ---------------
            Total Requests:         232,431.0       194,452.3        37,978.7
         Database Requests:         228,909.4       194,447.9        34,461.5
        Optimized Requests:               0.0             0.0             0.0
             Redo Requests:           3,515.1             0.3         3,514.8
                Total (MB):           1,839.6         1,519.2           320.4

Ok so we’re looking at 1519 MB/sec of read throughput and 320 MB/sec of write throughput. Crucially, the lines are nice and consistent – with very little deviation from the mean. By dividing the amount of time spent waiting on db file sequential read (i.e. random physical reads) with the number of waits, we can calculate that the average latency for random reads was 438 microseconds.

Now we know what to expect, let’s look at the result from the hypervisor tests.

Results: VMware vSphere

VMware is configured to use Raw Device Mapping (RDM) which essentially gives the benefits of raw devices… read here for more details on that. Here are the test results:

Oracle SLOB- 8 Hour Sustained Throughput Test with VMware ESXi 5.5.1 (SLC)

IO Profile                  Read+Write/Second     Read/Second    Write/Second
~~~~~~~~~~                  ----------------- --------------- ---------------
            Total Requests:         173,141.7       145,066.8        28,075.0
         Database Requests:         170,615.3       145,064.0        25,551.4
        Optimized Requests:               0.0             0.0             0.0
             Redo Requests:           2,522.8             0.1         2,522.7
                Total (MB):           1,370.0         1,133.4           236.7

Average read throughput for this test was 1133 MB/sec and write throughput averaged at 237 MB/sec. Average read latency was 596 microseconds. That’s an increase of 36%.

In comparison to the bare metal test, we see that total bandwidth dropped by around 25%. That might seem like a lot but remember, we are absolutely hammering this system. A real database is unlikely to ever create this level of sustained I/O. In my role at Violin I’ve been privileged to work on some of the busiest databases in Europe – nothing is ever this crazy (although a few do come close).

Results: Oracle VM

Oracle VM is based on the Xen hypervisor and therefore uses Xen virtual disks to present block devices. For this test I downloaded the Oracle Linux 6 Update 5 template from Oracle’s eDelivery site. You can see more about the way this VM was configured here. Here are the test results:

Oracle SLOB- 8 Hour Sustained Throughput Test with Oracle VM 3.3.1 (SLC)

IO Profile                  Read+Write/Second     Read/Second    Write/Second
~~~~~~~~~~                  ----------------- --------------- ---------------
            Total Requests:         160,563.8       134,592.9        25,970.9
         Database Requests:         158,538.1       134,587.3        23,950.8
        Optimized Requests:               0.0             0.0             0.0
             Redo Requests:           2,017.2             0.2         2,016.9
                Total (MB):           1,273.4         1,051.6           221.9

This time we see average read bandwidth of 1052MB/sec and average write bandwidth of 222MB/sec, with the average read latency at 607 microseconds, which is 39% higher than the baseline test.

Meanwhile, total bandwidth dropped by 31%. That’s slightly worse than VMware, but what’s really interesting is the deviation. Look at how ragged the lines are on the OVM test! There is a much higher degree of variance exhibited here than on the VMware test.


This is only one test so I’m not claiming it’s conclusive. VMware does appear to deliver slightly better performance than OVM in my tests, but it’s not a huge difference. However, I am very much concerned by the variance of the OVM test in comparison to VMware. Look, for example, at the wait event histograms for db file sequential read:

Wait Event Histogram
-> Units for Total Waits column: K is 1000, M is 1000000, G is 1000000000
-> % of Waits: value of .0 indicates value was <.05%; value of null is truly 0
-> % of Waits: column heading of <=1s is truly <1024ms, >1s is truly >=1024ms
-> Ordered by Event (idle events last)

                                                             % of Waits
Hypervisor  Event                   Waits  <1ms  <2ms  <4ms  <8ms <16ms <32ms  <=1s   >1s
----------- ----------------------- ----- ----- ----- ----- ----- ----- ----- ----- -----
Bare Metal: db file sequential read 5557.  98.7   1.3    .0    .0    .0    .0
VMware ESX: db file sequential read 4164.  92.2   6.7   1.1    .0    .0    .0
Oracle VM : db file sequential read 3834.  95.6   4.1    .1    .1    .0    .0    .0    .0

The OVM tests show occasional results in the two highest buckets, meaning once or twice there were waits in excess of 1 second! However, to be fair, OVM also had more millisecond waits than VMware.

Anyway, for now – and for this setup at least – I’m sticking with VMware. You should of course test your own workloads before choosing which hypervisor works for you…

Thanks as always to Kevin for bringing Oracle SLOB to the community.

ASM Rebalance Too Slow? 3 Tips To Improve Rebalance Times


I’ve run into a few customers recently who have had problems with their ASM rebalance operations running too slowly. Surprisingly, there were some simple concepts being overlooked – and once these were understood, the rebalance times were dramatically improved. For that reason, I’m documenting the solutions here… I hope that somebody, somewhere benefits…

1. Don’t Overbalance

Every time you run an ALTER DISKGROUP REBALANCE operation you initiate a large amount of I/O workload as Oracle ASM works to evenly stripe data across all available ASM disks (i.e. LUNs). The most common cause of rebalance operations running slowly that I see (and I’m constantly surprised how much I see this) is to overbalance, i.e. cause ASM to perform more I/O than is necessary.

It almost always goes like this. The customer wants to migrate some data from one set of ASM disks to another, so they first add the new disks:

alter diskgroup data
rebalance power 11 wait;

Then they drop the old disks like this:

alter diskgroup data
drop disk 'DATA1','DATA2','DATA3','DATA4',
rebalance power 11 wait;

Well guess what? That causes double the amount of I/O that is actually necessary to migrate, because Oracle evenly stripes across all disks and then has to rebalance a second time once the original disks are dropped.

This is how it should be done – in one single operation:

alter diskgroup data
drop disk 'DATA1','DATA2','DATA3','DATA4',
rebalance power 11 wait;

A customer of mine tried this earlier this week and reported back that their ASM rebalance time had reduced by a factor of five!

By the way, the WAIT command means the cursor doesn’t return until the command is finished. To have the command essentially run in the background you can simply change this to NOWAIT. Also, you could run the ADD and DROP commands separately if you used a POWER LIMIT of zero for the first command, as this would pause the rebalance and then the second command would kick it off.

2. Power Limit Goes Up To 1024

Simple one this, but easily forgotten. From the early days of ASM, the maximum power limit for rebalance operations was 11. See here if you don’t know why.

From, if the COMPATIBLE.ASM disk group attribute is set to or higher the limit is now 1024. That means 11 really isn’t going to cut it anymore. If you are asking for full power, make sure you know what number that is.

3. Avoid The Compact Phase (for Flash Storage Systems)

An ASM rebalance operation comprises three phases, where the third one is the compact phase. This attempts to move data as close as possible to the outer tracks of the disks ASM is using.

Did you spot the issue there? Disks. This I/O-heavy phase is completely pointless on a flash system, where I/O is served evenly from any logical address within a LUN.

You can therefore avoid that potentially-massive I/O hit by disabling the compact phase, using the underscore parameter _DISABLE_REBALANCE_COMPACT=TRUE. Remember that you need to get Oracle Support’s permission before setting underscore parameters! Point your SR in the direction of the following My Oracle Support note:

What is ASM rebalance compact Phase and how it can be disabled (Doc ID 1902001.1)

Unfortunately it appears the parameter was deprecated in 12c, so from now on you have to set the ASM diskgroup attribute “_rebalance_compact” to FALSE (note the opposite value to that set at the instance level!), for example:


If you want to know more about this topic (for example, what the first two rebalance phases are), or indeed anything about ASM in general, I highly recommend the legendary ASM blogger that is Bane Radulovic a.k.a. ASM Support Guy.


An ASM rebalance potentially creates a lot of I/O, which means you may need to wait for a long time before it finishes. For that reason, make sure you understand what you are doing and make every effort to perform only as much I/O as you actually need. Don’t forget you can use the EXPLAIN WORK command to gauge in advance how much work is required.

Happy rebalancing!

Postcards from Storageland: Three Years At Violin


A few weeks ago, in what seems to be a truly modern phenomenon, I became aware that it was my third anniversary of joining Violin after I noticed a number of people congratulating me on LinkedIn. In many ways it feels like I’ve already been here for a lifetime, but it was only twelve months ago I was trying to think of a suitable flash-based pun for the title of an article just like this one. This year I opted out of the “Three years in a flash” headline, it seemed a bit too lame. Those NAND-based puns were only ever a flash in the pan.*

So what’s happened in the three years since I joined Violin? Well, quite a lot. When I signed up in early 2012 Violin was pioneering the flash array industry – and when I say pioneering I mean that, unlike in today’s crowded AFA market, it was a pretty lonely place. The only other all-flash array vendor with a presence was Texas Memory Systems (TMS), but they had seemingly gone into hibernation in the markets I had exposure to (as it turned out they were looking for a buyer, which they found in the form of IBM).

I was one of the first employees in EMEA, part of a business which was rapidly expanding due to a global reseller agreement with HP for our 3000 series array. The main enemy was the status quo – monolithic disk arrays from EMC, IBM, HP, HDS etc, perhaps with a smattering of SSDs to try and alleviate the terrible performance of random I/O. With the 3000 on HP’s price list and no real competition to worry about it seemed like the world was there for the taking. Time to pay of the mortgage.

Were we overconfident? Guilty of hubris, perhaps? We must have alienated a few people in the industry because I know not everyone felt sympathy for what happened next.

Pride Cometh Before A Fall

With hindsight, the $2.35 billion that HP paid for 3PAR meant it was unlikely to continue using Violin as a strategic product. HP may have a history of write downs, but it simply couldn’t justify OEMing the new 6000 series array with 3PAR still on the books so… it didn’t.

Meanwhile, EMC purchased a company that hadn’t yet shipped a product, IBM did its deal with TMS, Cisco bizarrely purchased Whiptail (which now appears to be suspended as a product) and a number of SSD-based flash array startups (e.g. Pure Storage) appeared on the market.

crash-chartAll of which meant that, when Violin went to IPO, things didn’t exactly go to plan. In fact, it eventually resulted in a change of management and the introduction of a new CEO and management team who have systematically transformed the company over the last year. But at the time, it felt like a roller coaster.

So why am I reminiscing about the bad times? Partly because I don’t want to gloss over the past, but also because I genuinely think that Violin has had to do a lot of growing up in the last year or so – and that’s a good thing. When I look at other flash vendors throwing FUD at each other, getting into legal disputes over employees or burning bridges with their channel partners to try and get their pre-IPO books look more attractive… I can’t help a wry smile. Youth, eh? Some people still have harsh lessons to learn.

From Niche to Platform

This year, on the third anniversary of my joining Violin, we announced an important new product – the 7000 series Flash Storage Platform. Until the FSP, Violin had generally competed in the niche performance-optimized market – what some people call Tier 0 – where the single most important attribute is… well, performance (think database workloads). We’ve been pretty successful there, mainly because the 6000 series was (and still is) unbelievably fast, but also partly because much of the competition competes lower down in the capacity-optimized market (where price per GB is key – think VDI workloads). But we also attracted a surprising amount of criticism for the lack of certain Data Services features, such as deduplication (a feature that I’ve never coveted for database workloads).

But with the Flash Storage Platform, Violin – and flash in general – is moving into a new, larger and much more demanding market: Tier 1 primary storage. This is the big playground where all the major disk array vendors are desperately trying to stem the losses from their legacy SAN products. flash-market-venn-diagramIt’s also a market which is nearly 15 times larger than the one we used to operate in. And most importantly, it’s the one where you need to be able to deliver on all three requirements of the Primary Storage Trinity:

  • Performance (high IOPS and low latency)
  • Data Services (lots of features, fully integrated)
  • Capacity Optimization (low $/GB price)

By complete coincidence, this product launch also coincides with the end of the Understanding Flash section of my blog series on Storage for DBAs (when I started the flashdba blog it was aimed at database administrators, but over time the intended audience has expanded to anyone with an interest in flash storage).

With that in mind, in the next set of posts I’ll be turning my attention to the concepts and architecture of All Flash Arrays. What defines an AFA? What needs to be considered when designing one? And why doesn’t it make sense to stuff a load of SSDs into an existing disk array in the hope that it will deliver the performance of All Flash?

This is a really exciting time to be working in the storage industry – there’s lots to do and a massive opportunity to embrace. Because of this, the blog posts haven’t been coming as quickly as I’d hoped. But I still have much I want to talk about… so don’t worry, the next one will be back in a flash.**

* I really will stop making flash-based puns now

** Apart from this one


Get every new post delivered to your Inbox.

Join 1,111 other followers
