Oracle ASMLib: Physical and Logical Blocksize

This article is about the use of Advanced Format devices on Oracle’s ASMLib kernel library for Linux. For background, read this page on 4k sector sizes first, otherwise it might all sound like nonsense. Mind you, it mind sound like nonsense anyway, I can’t guarantee anything here. By the way, a big hello to my buddy Nate who asked for this information: you rock, dude.

In more recent versions of ASMLib, Oracle introduced a new parameter into the /etc/sysconfig/oracleasm file:

[root@half-server4 mapper]# tail -5 /etc/sysconfig/oracleasm
# ORACLEASM_USE_LOGICAL_BLOCK_SIZE: 'true' means use the logical block size
# reported by the underlying disk instead of the physical. The default
# is 'false'

To understand what this parameter does, consider this device which I am presenting from a Violin array:

[root@half-server4 ~]# ls -l /dev/mapper/testlun
lrwxrwxrwx 1 root root 8 Feb 27 15:33 /dev/mapper/testlun -> ../dm-19
[root@half-server4 ~]# fdisk -l /dev/mapper/testlun

Disk /dev/mapper/testlun: 34.4 GB, 34359738368 bytes
255 heads, 63 sectors/track, 4177 cylinders
Units = cylinders of 16065 * 512 = 8225280 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 524288 bytes

The important bit there is highlighted in red. This device has a 4k physical blocksize (as all Violin devices do, as well as many other modern storage systems) but has a 512 byte logical blocksize. Essentially, this LUN is pretending to be a 512 byte based.

Now that’s all well and good. Operating systems and applications that cannot support 4k block sizes (e.g. Red Hat 5 and Oracle Linux 5) will happily use this, because they believe it to be 512 byte. But later versions of ASMLib have started being too clever for their own good.

Don’t Look Behind The Curtain

Let’s create an ASMLib label on this device:

root@half-server4 ~]# oracleasm createdisk TESTLUN /dev/mapper/testlun
Writing disk header: done
Instantiating disk: done

And now we can attempt to put an ASM diskgroup on it:

     'compatible.asm' = '11.2',
     'compatible.rdbms' = '11.2';
ERROR at line 1:
ORA-15018: diskgroup cannot be created
ORA-15038: disk '' mismatch on 'Sector Size' with target disk group [4096]

What happened? Well, ASMLib has looked behind the smoke and mirrors and decided that this is actually a 4k device. It’s therefore presenting this to Oracle ASM as 4k, which causes the problem (because I explicitly asked for sector size to be 512 byte on this diskgroup).

One possible solution is to change the ASM_DISKSTRING from it’s default value of NULL (meaning ‘ORCL:*’) to ‘/dev/oracleasm/disks/*’, i.e. the location where ASMLib creates its own block devices. We can test this theory with fdisk:

[oracle@half-server4 ~]$ ls -l /dev/oracleasm/disks/TESTLUN
brw-rw---- 1 oracle dba 252, 19 Feb 27 15:38 /dev/oracleasm/disks/TESTLUN
[oracle@half-server4 ~]$ fdisk -l /dev/oracleasm/disks/TESTLUN | grep "Sector size"
Sector size (logical/physical): 512 bytes / 4096 bytes

So that would work. But it would lose many of the claimed benefits of ASMLib such as reduced file descriptors and context switching. Also, it feels like a hack.


The answer, as you probably guessed, is to set this new parameter. It defaults, wrongly in my opinion, to using the physical block size. We can either edit the value in the file to be true in order to use the logical blocksize, or preferably use the oracleasm configure command:

root@half-server4 ~]# oracleasm configure -b
Writing Oracle ASM library driver configuration: done
[root@half-server4 ~]# oracleasm configure | grep ORACLEASM_USE_LOGICAL_BLOCK_SIZE

It can be set back to using the physical blocksize with the following command:

[root@half-server4 ~]# oracleasm configure -p
Writing Oracle ASM library driver configuration: done
[root@half-server4 ~]# oracleasm configure | grep ORACLEASM_USE_LOGICAL_BLOCK_SIZE

Finally, a word of warning. If you are like me, then you are a bit stupid and can’t follow instructions properly. I set the value of the parameter to TRUE in upper case and then spent hours wondering why it didn’t work. The answer, to my embarrassment, is that it’s case sensitive. TRUE is not a valid value so it defaults to false. Doh.


New script for setting up multipath.conf entries

I’ve added a new script to the Useful Scripts page called which automates the process of creating entries for the /etc/multipath.conf file on Red Hat 6 / Oracle Linux 6.

As the name suggests, I wrote it with Violin devices in mind, but there should be overlap with other storage which will potentially make it useful elsewhere… see here for more details.

Oracle Fixes The 4k SPFILE Problem…But It’s Still Broken

As anyone familiar with the use of Oracle on Advanced Format storage devices will know to their cost, Oracle has had some difficulties implementing support of 4k devices. Officially, support for devices with a 4096 byte sector size was introduced in Oracle 11g Release 2 (see section of the New Features Guide) but actually, if the truth be told, there were some holes.

(Before reading on, if you aren’t sure what I’m talking about here then please have a read of this page…)

I should say at this point that most 4k Advanced Format storage products have the ability to offer 512 byte emulation, which means any of the problems shown here can be avoided with very little effort (or performance overhead), but since 4096 byte devices are widely expected to take over, it would be nice if Oracle could tighten up some of the problems. After all, it’s not just flash memory devices that tend to be 4k-based: Toshiba, HGST, Seagate and Western Digital are all making hard disk drives that use Advanced Format too.

The SPFILE Problem in <

Given that 4k devices are allegedly supported in Oracle 11g Release 2 you would think it would make sense that you can provision a load of 4k LUNs and then install the Oracle Grid Infrastructure and Database software on them. But no, in versions up to and including this caused a problem with the SPFILE.

Here’s my sample system. I have 10 LUNs all with a physical and logical blocksize of 4k. I’m using Oracle’s ASMLib kernel driver to present them to ASM and the 4k logical and physical properties are preserved through into the ASMLib device too:

[root@half-server4 mapper]# fdisk -l /dev/mapper/slobdata1 | grep "Sector size"
Sector size (logical/physical): 4096 bytes / 4096 bytes
[root@half-server4 mapper]# oracleasm querydisk /dev/mapper/slobdata1
Device "/dev/mapper/slobdata1" is marked an ASM disk with the label "SLOBDATA1"
[root@half-server4 mapper]# fdisk -l /dev/oracleasm/disks/SLOBDATA1 | grep "Sector size"
Sector size (logical/physical): 4096 bytes / 4096 bytes

Next I’ve installed Grid Infrastructure and created an ASM diskgroup on these LUNs. As you can see, Oracle has successfully spotted the devices are 4k and correspondingly set the ASM diskgroup sector size to 4096:

ASMCMD> lsdg
State    Type    Rebal  Sector  Block       AU  Total_MB  Free_MB  Req_mir_free_MB  Usable_file_MB  Offline_disks  Voting_files  Name
MOUNTED  EXTERN  N        4096   4096  1048576    737280   737207                0          737207              0             N  DATA/

Time to install the database. I’ll just fire up the OUI and install the database software complete with a default database, choosing to locate the database files in this +DATA diskgroup. What could possibly go wrong?


The installer gets as far as running the database configuration assistant and then crashes out with the message:

PRCR-1079 : Failed to start resource ora.orcl.db
CRS-5017: The resource action "ora.orcl.db start" encountered the following error:
ORA-01078: failure in processing system parameters
ORA-15081: failed to submit an I/O operation to a disk
ORA-27091: unable to queue I/O
ORA-17507: I/O request size 512 is not a multiple of logical block size
ORA-06512: at line 4
. For details refer to "(:CLSN00107:)" in "/home/OracleHome/product/11.2.0/grid/log/half-server4/agent/ohasd/oraagent_oracle/oraagent_oracle.log".

Why did this happen? The clue is in the error message highlighted in red. Over the years that this has been happening (and trust me, it’s been happening for far too long) various notes have appeared on My Oracle Support, such as 1578983.1 and 14626924.8. The cause is the following bug:

Bug 14626924  Not able to read spfile from ASM diskgroup and disk with sector size of 4096

At the time of  writing, this bug is shown as fixed in and the 12.2 forward code stream, with backports available for,,, and Alternatively, there is the simple workaround (documented in my Install Cookbooks) of placing the SPFILE in a non-4k location.

What the heck, I have the binaries stored locally, so let’s fire it up and see the fixed SPFILE in action. with 4k Devices

As with the previous example, I have a set of 4k LUNs presented via ASMLib – I won’t repeat the output from above as it’s identical. The ASM diskgroup correctly shows the sector size as 4096, so we’re ready to install the database software and let it create a database. As before the database files will be located in the diskgroup – including the SPFILE – but this time, it won’t fail because bug 14626924 is fixed in right? Right?


Oh dear. That’s not the error-free installation we were hoping for. Also, one of my pet hates, why are these Clusterware messages so incredibly unhelpful? Looking in the oraagent_oracle.log file we find the following nugget of information:

ORA-01034: ORACLE not available
ORA-27101: shared memory realm does not exist
Linux-x86_64 Error: 2: No such file or directory
Process ID: 0
Session ID: 0 Serial number: 0

That’s not entirely useful either, so let’s try and fire up the database manually:

[oracle@half-server4 ~]$ sqlplus / as sysdba
SQL*Plus: Release Production on Wed Feb 12 17:56:29 2014
Copyright (c) 1982, 2013, Oracle.  All rights reserved.

Connected to an idle instance.
SQL> startup nomount
ORA-01078: failure in processing system parameters
ORA-17510: Attempt to do i/o beyond file size

Aha! The problem happens even attempting to start in NOMOUNT mode, so it seems likely this is related to reading the PFILE or SPFILE. Let’s just check to see what we have:

[oracle@half-server4 ~]$ ls -l $ORACLE_HOME/dbs/initorcl.ora
-rw-r----- 1 oracle oinstall 35 Feb 12 17:26 /u01/app/oracle/product/11.2.0/dbhome_1/dbs/initorcl.ora
[oracle@half-server4 ~]$ cat $ORACLE_HOME/dbs/initorcl.ora

Sure enough, we have an SPFILE located in the ASM diskgroup… and we cannot read it. Could it possibly be that even in there are problems with SPFILEs being located in 4k devices? Searching My Oracle Support for ORA-17510 initially draws a blank. But a search of the Oracle bug database for the previous bug number (14626924) brings up some interesting new bugs:


In the description of this bug, the following statement is made:

ORA-17510: Attempt to do i/o beyond file size after applying patch 14626924

1. create init file initvarial.ora in dbs directory with below

2. startup pfile=/u01/app/oracle/product/

SQL> startup pfile=/u01/app/oracle/product/
ORA-17510: Attempt to do i/o beyond file size

This looks very similar. Unfortunately this bug is marked as a duplicate of base bug 18016679, which sadly is unpublished. All we know about it is that, at the time of writing, it isn’t fixed – the status of the duplicate is still “Waiting for the base bug fix“.

So there we have it. The infamous 4k SPFILE issue is fixed in and replaced with something else that makes it equally unusable. For now, we’ll just have to keep those SPFILEs in 512 byte devices…

Update Feb 14th 2014

I kind of had a feeling that the above problem was in some way related to the use of ASMLib, so I thought I’d repeat the entire install using normal block devices. Essentially this means changing the ASM discovery path from it’s default value of ‘ORCL:*’ to the path of the device mapper multipath devices, which is my case is ‘/dev/mapper/slob*’.

This time we don’t even get through the Grid Infrastructure installation, which fails while running the Oracle ASM Configuration Assistance (asmca) giving the following error messages:

[main] [ 2014-02-14 15:55:22.112 GMT ] [UsmcaLogger.logInfo:143]  CREATE DISKGROUP SQL: CREATE DISKGROUP DATA EXTERNAL REDUNDANCY  DISK '/dev/mapper/slobdata1', '/dev/mapper/slobdata2', '/dev/mapper/slobdata3', '/dev/mapper/slobdata4',
'/dev/mapper/slobdata5', '/dev/mapper/slobdata6', '/dev/mapper/slobdata7', '/dev/mapper/slobdata8'
ATTRIBUTE 'compatible.asm'='','au_size'='1M'
[main] [ 2014-02-14 15:55:22.206 GMT ] [SQLEngine.done:2189]  Done called
[main] [ 2014-02-14 15:55:22.224 GMT ] [UsmcaLogger.logException:173]  SEVERE:method oracle.sysman.assistants.usmca.backend.USMDiskGroupManager:createDiskGroups
[main] [ 2014-02-14 15:55:22.224 GMT ] [UsmcaLogger.logException:174]  ORA-15018: diskgroup cannot be created
ORA-27061: waiting for async I/Os failed

It seems Oracle still has some way to go before this will work properly…

Oracle VM 3.1.1 with Violin Memory storage

Oracle-VMAs part of the Installation Cookbook series I have now posted a new entry on how to install Oracle VM with Violin Memory flash storage:

Oracle VM 3.1.1 with Violin Memory storage

Using Oracle Preinstall RPM with Red Hat 6

Recently I’ve been building Red Hat 6 systems and struggling to use the Oracle Preinstall RPM because it has a dependency on the Oracle Unbreakable Enterprise Kernel.

I’ve posted an article on this subject and my methods for getting around it:

Using Oracle Preinstall RPM with Red Hat 6

This system is not registered with ULN / RHN

One of the features of WordPress is the ability to see search terms which are taking viewers to your blog. One of the all-time highest searches bringing traffic to my site is “This system is not registered with ULN”… and sure enough if I search for that phrase on Google my site is one of the top links, taking people to one of my Violin Memory array Installation Cookbooks.

So I guess it’s only fair that I give these passers by some sort of advice on what to do if you see this message…

1. Don’t Panic

Chances are you have built a new Linux system using Red Hat Enterprise Linux or its twin sister Oracle Linux. You are probably now trying to use yum to install software packages, but every time you do so you see something similar to this:

# yum install oracle-validated -y
Loaded plugins: rhnplugin, security
This system is not registered with ULN.
ULN support will be disabled.
ol5_u7_base | 1.1 kB 00:00
Setting up Install Process
Resolving Dependencies
--> Running transaction check
---> Package oracle-validated.x86_64 0:1.1.0-14.el5 set to be updated

This is the Oracle Linux variant. If it was Red Hat you would see:

This system is not registered with RHN
RHN support will be disabled.

The first thing to understand is that you can quite happily build and run a system in this state – in fact I’m willing to bet there are many systems out there exhibiting this message every time somebody calls yum.

The message simply means that you have not registered this build of your system with Oracle or Red Hat. Both companies have a paid support offering which allows you to register a system and do things like get software updates. Red Hat’s is call the Red Hat Network (RHN) and Oracle’s, with their marketing department’s usual sense of humour, is called the Oracle Unbreakable Linux Network (ULN). [I’ve been critical of some Oracle products in the past but I have to say that I love Oracle Linux, even if I do find the name “Unbreakable” a bit daft…]

You don’t have to register your system with the vendor’s support network in order to be able to use it. I’m not making any statements about your support contract, if you have one – I’m just saying that it will work quite normally without it.

2. Register Your System

If you have Oracle or Red Hat support then you might as well register your system so that it can take advantage of their yum channels.

In systems prior to RHEL6 / OL6 you used a utility called up2date to register:

# up2date --register

Or if you want to use the text-mode version:

# up2date-nox --register

You can find a good tutorial explaining the process here. In RH6 / OL6 the process changed, so now you call the relevant utility.

For Red Hat you need to use the rhn_register command (actually this also became available in RHEL5). You will need your Red Hat Network login and password.

For Oracle Linux you need to use the uln_register command. You will need your Oracle ULN login, password and Customer Service Identifier (CSI).

Once your registration is complete the message “This system is not registered” should leave you alone.

3. Don’t Have Support?

Of course, not everybody has a support contract with Red Hat or Oracle. Some people have one but can’t find the details. Others can’t be bothered to set it up. If any of these applies to you then there is another alternative, which is the Oracle Public Yum Server. [Fair play to Wim and the team for making this available, because it’s been making my life easier for years now…]

Oracle’s public yum server is a freely available source of Linux OS downloads. Simply point your browser here and follow the instructions:

In essence, you use wget to download the Oracle repo file which relates to your system and then (optionally) edit it to choose the yum channel you want to subscribe to (otherwise it will use the latest publicly-available stuff). The versions of the Linux software on the public yum repositories are (I believe) not as up-to-date as those you would get if you subscribed to a support contract, but they are still very new.

And the best bit is you can also use it if you have Red Hat installed; it isn’t restricted to Oracle Linux users. Having said that, make sure you don’t do anything which invalidates your support contracts. By pointing a RHEL system at the Oracle public yum server and running an update you are effectively converting your system to become Oracle Linux.

Here’s an example of how to set it up for OL6:

# cd /etc/yum.repos.d
# wget

This gets yum working and so allows for the Oracle Validated / Oracle Preinstall RPM to be installed in order to setup the database…

Hopefully that will satisfy some of my wayward blog visitors!
