I was recently contacted by a customer who runs a busy ERP system on their Oracle database. Their users have been screaming for some time about unpredictable performance, where application screens which would usually open in under a second suddenly take an age. ERP systems are legendary for this, of course, because as each screen loads the application tends to fire off a glut of queries to populate all the various fields, graphs and so on. When performance problems strike, the elapsed time for each query rises, which usually results in “stuff going slowly”. And unfortunately, because of something known to psychologists as the availability heuristic, users tend not to remember the times when performance was acceptable… just the occasions when they were left frustrated.

Initial Investigation

The first thing I ask for in situations like this is a set of AWR reports. Customers are generally happy to part with such information, whereas the running of bespoke SQL scripts to harvest data can often cause delays as the scripts have to be investigated and tested. AWR reports, I’m sure you know, contain information about the behaviour and performance of the database between two points in time – and much of the data is averaged. For this reason, I always always ask for a set of multiple, consecutive reports covering the problematic period where each report covers no more than one hour. I’d prefer less than one hour per report, but the default configuration of Oracle results in hourly snapshots so that’s usually the limit… as it was for this customer.

As a first pass, I like to run the AWR reports through my awr-parser.sh script. This parses them all and produces a CSV file as output. This can then be easily used to graph information such the amount of time spent working on CPU versus time spent waiting on I/O requests to complete. Often this is enough to get a basic idea of what’s happening….

In the above graph, each column shows data from a single (hourly) AWR report; blue represents DB CPU while red represents User I/O wait time. If we are looking to increase the user experience with low-latency storage then we would hope to find two things: a) lots of User I/O wait time, and b) average latency which is higher than we would expect a flash array to deliver.

Unfortunately, the first requirement isn’t really there in the above graph. There just isn’t enough red, except for peaks towards the end of the day where there appears to be some batch job or backup taking place. A peak at the AWR reports shows that this is in fact a scheduled job which performs an online rebuild of an index. With more capable storage we could make this go a lot faster, so would that perhaps help the customer?

Sadly, the answer was no, it wouldn’t. The customer specifically stated that it’s the online day where they struggle and not the index rebuild. Hmmm.

More Graphs

Let’s have a look at some of the other information that came out of the AWR reports to see if anything interesting shows up:

Plenty of spare CPU capacity here. In fact, if you think about how much Oracle licenses cost per CPU – and how much CPU is not being used… it looks like this database server represents a significant over-investment.

Not much in the way of I/O… there are spikes here and there, including those for the index rebuilds, but overall the I/O rates are very low and for many samples we barely scratch 10MiB/sec.

So what have we got? A system which hardly performs any I/O and doesn’t seem to spend any time waiting on I/O during the period the users are complaining about. Time to go back to the customer and ask for some more detail…

Second Attempt

After a plea for more details, I received another batch of AWR reports covering a single 24 hour period, as well as the crucial information that complaints were received between 5am and 6am. Perfect. Let’s have a look at that throughput graph again:

Again, the throughput is very low – including around the critical 5am-6am period where complaints were received – which might fool us into thinking any problems are not related to the storage. But what about if we plot a graph of I/O Operations Per Second (IOPS)?

Bingo! There’s a big spike of read IOPS at exactly the time where problems were reported, which we can put down to a large amount of random physical reads. We know from the customer that they have a multi-controller monolithic disk array – the top of the range product from the world’s biggest disk array vendor. But it’s still a disk array, which means random I/O frequently results in high latency as somewhere a disk head has to move across the platter and then the platter has to rotate to the correct sector.

So we should be able to just check the average wait time for random physical reads (the wait event db file sequential read) and it will reveal itself as the problem. Right? We’ll expect to see waits in the region of 4-8ms or perhaps even worse if it’s really struggling.

Here’s a graph of the average user I/O wait time seen across each AWR report – don’t forget we’re especially interested in the troublesome 5am-6am period:

Not what we expected. The 5am-6am slot is showing the best latency figures for the entire day! And this is when users are complaining?

Averages Lie

A disk array like this usually has a reasonably large DRAM cache and quite possibly a set of SSDs being used for further caching or tiering of data. If a physical read can be satisfied from the cache, it will likely be serviced in under a millisecond. But if we experience a cache miss, we’re forced to pay the penalty of mechanical latency and wait for many milliseconds. Thus there are two ranges of response times: sub-millisecond and many milliseconds.

Average wait times won’t show this because they are simply the average of all waits over the period of the AWR report (an entire hour in this case). What if many of the reads are cache hits but some still miss? Maybe it’s possible that there are enough misses to cause users to complain, but enough hits to make the average look acceptable?

Luckily, there is another section in the AWR report which can help here: the Wait Event Histogram. Here’s the histograms covering db file sequential read waits (random physical reads) for our 24 hour period:

$ cat header.txt; for file in `ls -1`; do
grep -A 40 "Wait Event Histogram" $file | grep "db file sequential read" | head -1
done
                                                    % of Waits
                                 -----------------------------------------------
                           Total
Event                      Waits  <1ms  <2ms  <4ms  <8ms <16ms <32ms  <=1s   >1s
-------------------------- ----- ----- ----- ----- ----- ----- ----- ----- -----
db file sequential read     3329  99.2    .8    .0    .0    .0    .0    .0    .0
db file sequential read     3487  99.4    .6    .0    .0
db file sequential read    35.4K  21.0   1.2   2.5  23.2  39.0  11.9   1.1
db file sequential read    82.9K  34.6   1.8   3.4  15.9  31.9  11.2   1.2
db file sequential read    428.6  67.4   2.1   2.5  10.1  15.2   2.4    .3
db file sequential read    4440.  92.6   1.3   1.2   1.9   2.6    .4    .0
db file sequential read    2013K  91.7   1.4   1.2   2.1   3.0    .5    .0
db file sequential read    131.7  45.7   1.1   2.8  15.6  29.1   5.4    .3
db file sequential read    76.3K  20.7   1.7   2.8  21.7  44.0   8.7    .4
db file sequential read    83.7K  31.1   1.1   2.4  16.6  38.1  10.0    .7
db file sequential read    430.4  79.6   1.5   2.0   4.4   9.3   2.9    .3
db file sequential read    106.6  32.3   1.7   3.0  15.4  36.1  10.3   1.2
db file sequential read      94K  23.8   1.8   2.7  16.6  41.7  12.1   1.2
db file sequential read    248.6  36.0   1.8   2.9  14.8  34.5   8.9   1.1
db file sequential read    202.5  31.9   1.4   2.0   9.0  38.0  16.1   1.6
db file sequential read    237.7  20.2   1.9   2.9  17.7  43.5  12.5   1.2
db file sequential read    49.5K   9.4   1.0   2.7  24.1  48.0  13.6   1.1
db file sequential read    75.6K  42.4   1.5   3.0  16.9  29.9   5.9    .5
db file sequential read    88.7K  61.4   1.3   2.5  12.4  18.2   3.8    .4
db file sequential read    644.3  84.3   1.0   1.5   4.3   7.3   1.5    .2
db file sequential read    61.3K  34.9   6.9   4.4  11.0  31.2  10.5   1.1
db file sequential read      330  96.7   3.1    .2    .0    .0
db file sequential read      12K  88.7   9.5   1.2    .4    .2    .1    .0    .0

Now the problem becomes clear. Although many reads are hitting the cache (<1ms bucket), there are an awful lot that are missing. The <2ms and <4ms buckets are virtually empty and then around <8ms we start to see big numbers again. Those are cache misses which incur the penalty of seek time on a hard disk drive somewhere in the array.

What’s more, it’s clear that the array is under some pressure because in many of the AWR reports there are substantial waits in the <16ms and above buckets. I’ve highlighted in red the occasions where over one third of read requests took over 8ms. That’s exactly the sort of behaviour that is making people replace disks with flash.

Let’s visualise the above data. I’ve gone back to the older set of AWR reports and graphed the histogram buckets to see if we can get a feel for the distribution of waits:

As you can see, I’ve tried to go for a heat map-style colour scheme, with green indicating cache hits on the storage array and the colours moving from yellow through orange to red indicating cache misses which result in disk drive seek time. There are also some real outliers in black where requests took over one thousand milliseconds to be serviced (ouch).

Another way to look at it is to make the picture clearer by reducing the detail. In the graph below I’ve simply assumed that everything sub-millisecond is a storage array cache hit and everything else is a miss:

Clearly there are a lot of physical reads paying the price of mechanical latency here.

Conclusion

What this customer does next is up for debate – there are more than just technical issues to consider. But the point of this post is to illustrate that while average wait times are great for getting a rough feel of how a system is behaving, they also offer huge scope to lose details. And sometimes those details are important. The devil, as they say, is truly in the detail…

Update: January 2015 – I have now added the ability to read Wait Event Histograms to my awr-parser.sh script which you can find on my Useful Scripts page…

Filed under AWR Reports, Blog, Database, Storage Tagged with AWR reports, database, oracle

Oracle, Parallelism and Direct Path Reads… on Flash

September 3, 2014 2 Comments

Guest Post

This is another guest post from my buddy Nate Fuzi, who performs the same role as me for Violin but is based in the US instead of EMEA. Because he’s an American, Nate believes that “football” is played using your hands and that the ball is actually egg-shaped. This is of course ridiculous, because as the entire rest of the world knows, this is football whereas the game Nate is thinking of is actually called “HandEgg”. Now that we’ve cleared that up, over to you, Nate:

Lately, I’ve been running into much confusion around Oracle’s direct path IO functionality (11g+) and, unusually, not all of that confusion is my own. There is a perplexing lack of literature and experimentation with direct path IO on the Internet today. Seriously, I’ve looked. I decided I needed to better understand this event and its timing in order to properly extend suggestions to customers. I set about trying to prove some things I thought I knew, and I managed to confirm several suspicions but also surprised myself with some unexpected results. I’d like to share these in hopes of clarifying this event for everyone in practical terms.

Direct Path IO Background

To set the stage a bit, at the highest level, Oracle created the direct path IO event to describe an IO executed by an Oracle process that reads into (or writes from) the process global area (think of this as the session’s private memory) directly from (to) storage, bypassing the Oracle buffer cache. The rationale is this: full table scans of large tables into the buffer cache consume a lot of space, pushing out likely useful buffers in favor of buffers unlikely to be needed again in the near future. Reading directly into the process global area instead of the shared global area keeps full table scans from polluting the buffer cache and diminishing its overall effectiveness. Since the direct path IO is used for full scanning large objects, it looks to the database’s DB_FILE_MULTIBLOCK_READ_COUNT (henceforth referred to as DBMRC) setting for guidance on the size of IO calls to issue.

Makes sense. But what’s been confusing me is the apparently inconsistent performance of direct path reads and writes, even against Violin’s all-flash arrays. With random and other multi-block IO events showing very low, consistent performance, direct path reads can still be all over the board. How is that? Is it truly impacting performance? How can I make it better, or should I even try? After seeing this at a number of customer installations, I decided to run some tests on a smallish lab server attached to a single Violin array.

The Setup

I have a test database with a number of tables almost exactly 125GB in size full of randomized data. Full-scanning one of these tables via “select count(*)” was plenty to exercise the direct path read repeatedly, varying parallelism and DBMRC. My goal was to see the effect of these settings on both elapsed time and perceived latency. With an 8K database block size (RHEL 6.3, Oracle 12.1.0.1, ASM), I ran the test with DBMRC set to 4, then 8, 16, and finally 128. I ran each test with no parallelism, then with “parallel 16” hinted. So what did I see?

Test Results

Note that elapsed times represent the time my query returned to the SQL*Plus prompt with the “set timing on” directive applied to my session and are not 100% representative of time spent on the database but are close enough for my purposes. Total direct path read (DPR) time was pulled from the respective AWR report after execution finished. I asterisked the Physical Read Requests column because some of the reports showed 0 physical reads for the test SQL, while it was clear from the total physical reads that my read operation was the only possible culprit; therefore I felt justified in attributing that total (minus a few here and there from the AWR snapshotting process) to the test SQL. Note also that the best elapsed time was achieved with the lowest DBMRC and parallel 16. Worst time by far was also obtained with DBMRC set to 4 but without parallelism—although it accumulated the least amount of wait time on DPR. In general, throwing more cores at the problem improved performance hugely; not surprising, but noteworthy. We know that flash does not benefit from multi-block IO as a rule: at the lowest level, every IO is effectively a random IO, and larger blocks / groups of blocks are fetched independently, assembled, and returned to the caller as a single unit. However, there is a definite overhead in issuing IO requests, waiting for the calls to return, and consuming the requested data. This is evidenced by the high elapsed time for the single-threaded run with DBMRC set to 4: the least amount of reported IO wait time still contributed to the longest overall elapsed time.

So what do these values tell us? For one thing, parallelism is your friend. One core performing a FTS just isn’t going to get the job done nearly as quickly as multiple cores. Also, parallelism vastly trumps DBMRC as a tool for improving performance on flash when CPU resources are available. Performance between parallel processing runs was within 2%, no matter what the DBMRC setting. This I expected, having come into the testing with the assumption that DBMRC was irrelevant when working with flash. I was surprised at the exceedingly high elapsed time with the single-threaded query using small DBMRC. I would expect that to be higher than the others, but not nearly 3X longer than the single-threaded run with DBMRC at 128.

These revelations are mildly interesting, but what I find much more curious is the difference in reported DPR latency. Certainly, a highly parallel execution can accumulate more database time than wall clock time for any event. But we can tell from the elapsed times that, when we’re not starving the database for parallelism, DBMRC is practically meaningless when applied to flash. Yet the calculation of the average latency of the event is mysterious in that 1) 16 threads operating with DBMRC of 128 experiences roughly 4X the number of waits the single-threaded execution performs; 2) it does so apparently at about 13X the average latency of the single-threaded run; and 3) it racks up about 51X the amount of total DPR wait time.

What’s worse is that DPR stats are very strangely represented in the Tablespace IO stats section of the report. Here’s the snippet from test run #2:

                     Av       Av     Av      1-bk  Av 1-bk          Writes   Buffer  Av Buf
Tablespace   Reads   Rds/s  Rd(ms) Blks/Rd   Rds/s  Rd(ms)  Writes   avg/s    Waits  Wt(ms)
---------- ------- ------- ------- ------- ------- ------- ------- ------- -------- -------
DEMO       4.1E+06  49,395     0.0     4.0       2     0.0       0       0        0     0.0

We have to cut Oracle some slack on the Av Rds/s value here because it’s now averaging over the time it took me to start the test after my initial snapshot, then realize the test was done and execute another AWR snapshot to end the reporting period. Fine. But an average read time of 0.0ms?! Clearly, Oracle is recording some number of reads, but it’s not reporting timing on them at all in this section of the report. We have to look to the SQL Ordered by Physical Reads (Unoptimized) section of the report to confirm it’s actually doing a relevant number of IO requests:

-> Total Physical Read Requests:       4,092,389
-> Captured SQL account for    0.0% of Total
-> Total UnOptimized Read Requests:       4,092,389
-> Captured SQL account for    0.0% of Total
-> Total Optimized Read Requests:               1
-> Captured SQL account for    0.0% of Total

[some lines removed]

UnOptimized   Physical              UnOptimized
  Read Reqs   Read Reqs Executions Reqs per Exe   %Opt %Total    SQL Id
----------- ----------- ---------- ------------ ------ ------ -------------
          0           0          1          0.0    N/A    0.0 4kpvpt49hm3nf
Module: SQL*Plus
   PDB: DEMO
select /*+ parallel 16 */ count(*) from demo.length100_1

Oh, wait. Oracle doesn’t credit my query with any physical read requests. I have to look at the total just above in the report, and see that only the AWR snapshot performed any other IO on the system, and subtract that from the total. Sigh. At least ~4.1M reads at 32KB comes close to 125GB.

So what gives, Oracle? I’ve read some Oracle notes and other blogs on the subject of DPR, and they suggest the wait event is not necessarily triggered when the IO call is initially issued, but instead when the session decides it needs all outstanding DPR IOs it has issued to complete before moving on—or it fills up all its “slots” and has to wait for those to free up. Thus the under-reporting of the actual number of DPR waits and the artificially high wait time for each of those waits: fewer waits, along with potentially many IO requests outstanding when the wait is triggered and timing starts. But nowhere in all of this is there a set of numbers that I can trust to accurately describe my DPR performance. The fact that DPR IO is completely left out of tablespace timings is seriously troubling: we trust these stats to determine “hot” tablespaces and under-performing mount points. This throws all kinds of doubt into the mix.

What can I say about Oracle’s DPR at this point? While it works just fine and serves its purpose, the instrumentation appears to be lacking, even in Oracle 12.1. After this testing, I feel even more confident telling customers to ignore the latency reported for this event—at least for now. And I’ve confirmed my belief that, with any sort of parallelism enabled on your database, DBMRC is largely irrelevant for flash storage and only adds a mystery factor to reported latencies. Yes, setting this to a low value will affect costing of FTS vs. index access, so you should verify that plans currently employing FTS that you want to remain that way still do. This is easy enough with an alter session and explain plan. With that, Oracle, the ball is in your court: please define your terms, fix your instrumentation around DPR, or tell customers to stop worrying about DPR latencies. Meanwhile, I’m going to advise people who are otherwise happy with their performance but want better latency numbers in their reports to set DBMRC lower and get on with their lives.

Filed under Blog, Database, Flash, Storage Tagged with database, flash memory, oracle

Viewing ASM trace files in VIM: Which Way Do You Use?

August 20, 2014 2 Comments

A couple of people have asked me recently about a classic problem that most DBAs know: how to view ASM trace files in the VIM editor when the filenames start with a + character. To my surprise, there are actually quite a few different ways of doing it. Since it’s come up, I thought I’d list a few of them here… If you have another one to add, feel free to comment. I know that most people reading this already have an answer, I’m just interested in who uses the most efficient one…

The Problem

VIM is a text editor used in many different operating systems. You know the one, it’s incredibly powerful, utterly incomprehensible to the newcomer… and will forever have more options than you can remember. I mean, just check out the cheat sheet:

Courtesy of http://sheet.shiar.nl/

People love or hate vim (I love it), but it’s often used on Linux systems simply because it’s always there. The problem comes when you want to look at ASM trace files, because they have a silly name:

oracle@server3 trace]$ pwd
/u01/app/oracle/diag/asm/+asm/+ASM/trace
[oracle@server3 trace]$ ls -l +ASM_ora_27425*
-rw-r----- 1 oracle oinstall 20625 Aug 20 15:42 +ASM_ora_27425.trc
-rw-r----- 1 oracle oinstall   528 Aug 20 15:42 +ASM_ora_27425.trm

Oracle trace files tend to have names in the format <oracle-sid>-<process-name>-<process-id>.trc, which is fine until the Oracle SID is that of the Automatic Storage Management instance, i.e. “+ASM”.

It’s that “+” prefix character that does it:

[oracle@server3 trace]$ vim +ASM_ora_27425.trc

Error detected while processing command line:
E492: Not an editor command: ASM_ora_27425.trc
Press ENTER or type command to continue

Why does this happen? Well because in among the extensive options of vim are to be found the following:

[oracle@server3 trace]$ man vim
...
OPTIONS
       The  options may be given in any order, before or after filenames.  Options without an argument can be combined after a
       single dash.

       +[num]      For the first file the cursor will be positioned on line "num".  If "num" is missing, the  cursor  will  be
                   positioned on the last line.

       +/{pat}     For  the first file the cursor will be positioned on the first occurrence of {pat}.  See ":help search-pat-
                   tern" for the available search patterns.

       +{command}
...

So… the plus character is actually being interpreted by VIM as an option. Surely we can just escape it then, right?

[oracle@server3 trace]$ vim \+ASM_ora_27425.trc

Error detected while processing command line:
E492: Not an editor command: ASM_ora_27425.trc
Press ENTER or type command to continue

Nope. And neither single nor double quotes around the filename work either. So what are the options?

Solution 1: Make Sure The “+” Isn’t The Prefix

Simple, but effective. If the + character isn’t leading the filename, VIM won’t try to interpret it. So instead of a relative filename, I could use the absolute:

[oracle@server3 trace]$ vi /u01/app/oracle/diag/asm/+asm/+ASM/trace/+ASM_ora_27425.trc

Or even just use a ./ to denote the current directory:

[oracle@server3 trace]$ vi ./+ASM_ora_27425.trc

Solution 2: Double Dash

Even simpler, but less well known (I think?) is the double-dash or hyphen option. If you browse the VIM man page a little further on, you’ll find this:

[oracle@server3 trace]$ man vim
...
 --          Denotes  the end of the options.  Arguments after this will be handled as a file name.  This can be used to
                   edit a filename that starts with a ’-’.
...

And it works perfectly:

[oracle@server3 trace]$ vi -- +ASM_ora_27425.trc

Solution 3: Use Find and -Exec

Another, slightly messy option is to use the find command to send the file to VIM. I know people who still do this, despite it being more work than the other options – sometimes a lazy hack can become unconscious habit:

[oracle@server3 trace]$ find . -name +ASM_ora_27425.trc -exec vi {} \;

In fact, I actually know somebody who used to look up the file’s inode number and then pass that into find:

[oracle@server3 trace]$ ls -li +ASM_ora_27425*
138406 -rw-r----- 1 oracle oinstall 20625 Aug 20 15:42 +ASM_ora_27425.trc
138407 -rw-r----- 1 oracle oinstall   528 Aug 20 15:42 +ASM_ora_27425.trm
[oracle@server3 trace]$ find . -inum 138406 -exec vi {} \;

Luckily nobody will ever know who that somebody is*.

Solution 4: Rename It

My least favourite option, but it’s actually quite efficient. Simple create a copy of the file with a new name that doesn’t contain a plus – luckily the cp command doesn’t care about the + prefix:

[oracle@server3 trace]$ cp +ASM_ora_27425.trc me.trc
[oracle@server3 trace]$ vi me.trc

Of course, you’ll want to tidy up that new file afterwards and not just leave it lying around… won’t you?

Less Is More

Maybe you’re not the sort of person that likes to use VIM. Maybe you prefer the more basic OS tools like cat (which works fine on ASM trace files), or more (which doesn’t), or even less.

In fact, less has pretty much the same options as VIM, which means you can use all of the above solutions with it. If you are using more, you cannot pass this a double dash but the others will work. And if you’re using cat, good luck to you… I hope you have a big screen.

* Yes, of course, it was me.

Filed under ASM, Blog, Database, Linux Tagged with ASM, database, linux, oracle
