All Flash Arrays: Controllers Are The New Bottleneck

bottleneck

Today’s storage array market contains a wild variation of products: block storage, file storage or object storage; direct attached, SANs or NAS systems; fibre-channel, iSCSI or Infiniband… Even the SAN section of the market is full of diversity: from legacy hard disk drive-based arrays through the transitory step of tiered disk+flash hybrid systems and on to modern All-Flash Arrays (AFAs).

If you were partial to the odd terrible pun, you might even say that it was a bewildering array of choices. [*Array* of choices? Oh come on. If you’re expecting a higher class of humour than that, I’m afraid this is not the blog for you]

Anyway, one thing that pretty much all storage arrays have in common is the basic configuration blocks of which they comprise:

  • Array controllers
  • Internal networking
  • Persistent Media (flash or disk)

Over the course of this blog series I’ve talked a lot about both flash and disk media, but now it’s time to concentrate a little more on the other stuff – specifically, the controllers. A typical Storage Area Network delivers a lot more functionality than would be expected from just connecting a bunch of disks or flash – and it’s the controllers that are responsible for most of that added functionality.

Storage Array Controllers

Think of your storage system as a private network on which is located a load of dumb disk or flash drives. I say dumb because they can do little else other than accept I/O requests: reads and writes. The controllers are therefore required to provide the intelligence needed to present those drives to the outside world and add all of the functionality associated with enterprise-class storage:air-traffic-control

  • Resilience, automatic fault tolerance and high availability, RAID
  • Mirroring and/or replication
  • Data reduction technologies (compression, deduplication, thin provisioning)
  • Data management features (snapshots, clones, etc)
  • Management and monitoring interfaces
  • Vendor support integration such as call-home and predictive analytics

Controllers are able to add this “intelligence” because they are actually computers in their own right, acting as intermediaries between the back-end storage devices and the front-end storage fabric which connects the array to its clients. And as computers, they rely on the three classic computing resources (which I’m going to list using fancy colours so I can sneak them up on you again later in this post):

  1. Memory (DRAM)
  2. Processing (CPU)
  3. Networking

It’s the software running on the array controllers – and utilising these resources – that describes their behaviour. But with the rise of flash storage, this behaviour has had to change… drastically.

boxing-afa-hdd

Disk Array Controllers vs Flash Array Controllers

In the days when storage arrays were crammed full of disk drives, the controllers in those arrays spent lots of time waiting on mechanical latency. This meant that the CPUs within the controllers had plenty of idle cycles where they simply had to wait for data to be stored or retrieved by the disks they were addressing. To put it another way, CPU power wasn’t such an important priority when specifying the controller hardware.

This is clearly not the case with the controllers in an all flash array, since mechanical latency is a thing of the past. The result is that controller CPUs now have no time to spare – data is constantly being handled, addressed, moved and manipulated. Suddenly, the choice of CPU has a direct effect on the array’s ability to process I/O requests.

Dedupe Kills It

But there’s more. One of the biggest shifts in behaviour seen with flash arrays is the introduction of data reduction technology – specifically deduplication. This functionality, known colloquially as dedupe, intervenes in the write process to see if an exact copy of any written block already exists somewhere else on the array. copy-stampIf the block does exist, the duplicate copy does not need to be written – and instead a pointer to the existing version can be stored, saving considerable space. This pointer is an example of what we call metadata – information about data.

I will cover deduplication at greater length in another post, but for now there are three things to consider about the effect dedupe has on storage array controllers:

  1. Dedupe requires the creation of a fairly complex set of metadata structures – and for performance reasons much of this will need to reside in DRAM on the controllers. And as more data is stored on the array, the amount of metadata created increases – hence a growing dependency on the availability of (expensive) memory in those array controllers.
  2. The process of checking each incoming block (which involves calculating a hash value) and comparing against a table of metadata stored in DRAM is very CPU intensive. Thus array controllers which support DRAM have increasing requirements for (expensive) processing power.
  3. For storage arrays which run in an active/active configuration (i.e. with multiple redundant controllers, each of which actively send and receive data from the persistent storage layer), much of this information will need to be passed between controllers over the array’s internal networking.

Did you spot the similarities between this list and the colourful one from earlier? If you didn’t, you must be colour blind. Flash Array controllers are much more dependant on their resources – particularly CPU and DRAM – than disk array controllers.

Summary

Flash array controllers have to do almost everything that their ancestors, the venerable disk array controllers, used to do. But they have to do it much faster and in greater volume. bottleneck-signNot only that, but they have to do so much more… especially for the process known as data reduction. And as we’ve seen, the overhead of all these tasks causes a much greater strain on memory, processing and networking than was previously seen in the world of disk arrays – which is one of the reasons you cannot simply retrofit SSDs into a disk array architecture.

With the introduction of flash into storage, the bottleneck has moved away from the persistence layer and is now with the controllers. Over the next few articles we’ll look at what that means and consider the implications of various AFA architecture strategies on that bottleneck. After all, as is so often the case when it comes to matters of performance, you can’t always remove the bottleneck… but you can choose the one which works best for you 🙂

Advertisements

5 Responses to All Flash Arrays: Controllers Are The New Bottleneck

  1. Amir Hameed says:

    Hi Flashdba,
    Regarding dedupe on flash, it seems the advice is not to enable it?

    • flashdba says:

      Not at all. My advice is to consider the cost versus the benefits. Dedupe is a tradeoff: give some performance away in return for greater cost efficiency. I prefer to have the option of using dedupe on a per-volume basis, because some workloads make the tradeoff worthwhile and some do not. Oracle databases, for example, give almost zero returns on dedupe – so why use it?

  2. Amir Hameed says:

    What s your opinion about EMC’s Unity AFA 600/650 frames? I am unable to find latency information of their SSDs. Also, is 3D NAND only available in TLS?

    Thanks

    • flashdba says:

      I work for a competitor to DellEMC, so I’m hardly likely to say nice things about Unity. However, I will say what is already in the public domain, which is that Unity is DellEMC’s low-end offering. For enterprise flash storage, they also have their XtremIO AFA platform and the All-Flash variant of the ubiquitous VMAX array. You should ask yourself if the low-end solution is sufficient for your needs. What does “low-end” mean? It means the specifications of the controllers are lower (less performance, less cost) than that of XtremIO or VMAX. Which in turn means that you will get the performance of flash until you start to push the array, after which it will lose performance and you will have to think about disabling features such as compression and encryption. You can see that in the EMC best practice documents for Unity:

      https://web.archive.org/web/20180305100906/https://delltechnologiesworldonline.com/2017/connect/fileDownload/session/37C188D51953AC5746A3E07540827510/storage42.DellEMCUnity.BestPracticesForBestPerformance.pdf

      You can also find some interesting info from testing a Unity 600F array here:

      https://gruffdba.wordpress.com/2017/03/04/testing-emc-unity-storage-performance-with-slob/

      For your second question, do you mean TLC? 3D NAND and TLC are independent ways of increasing the density of NAND flash chips, so it is possible to manufacture SLC, MLC or TLC (and maybe QLC or beyond) in 3D. But nobody will manufacture it unless it is cost-effective, so – to my knowledge – 3D SLC has never been built. There were, if I remember, 3D MLC chips available on the market at one point (but don’t quote me on that). However, for the flash fabricators it really only makes sense to build 3D TLC, QLC or beyond.

      I must point out at this juncture that I am not an expert on the NAND flash marketplace, which is a fascinating area of study with more plot twists than Game of Thrones. If you want to learn more about that, I highly recommend the fantastic blogs of Mr Jim Handy at Objective Analysis:

      http://thememoryguy.com/
      http://thessdguy.com/

  3. Amir Hameed says:

    Thank you for pointing to the Unity testing link. We are currently on VMAX and since the lease is expiring, the data center is moving us to Unity 650. We are using FAST tiering on VMAX, so, we are currently using SSDs. I am collecting some SLOB data on the VMAX and then will compare it with data collected on Unity.
